Victron Phoenix Smart Charger 12V/30 2 Outputs

The Victron Phoenix Smart Charger delivers intelligent, dynamic charging to provide optimal care for lead acid batteries and Lithium-ion batteries.

The charger features an adaptive battery management system which automatically optimises the charge process. Bluetooth enabled, the charger is easy to monitor and set alarms. The charger is constructed with an aluminium enclosure and made with an IP43 rating for the electronic components and IP22 for the connection area.

The two-output configuration provides full rated-power to one outlet and three amps to the second; an excellent option for maintaining a starter battery. Whereas the three-output configuration provides full power to each outlet – ideal for simultaneously charging up to three separate banks of batteries. The 12V model is available with 30A or 50A, and the 24V model is available with 16A or 25A.

Benefits & Features

• Adaptive Battery Management: Lead-acid batteries must be charged in 3 phases: Bulk, absorption and float charging

• Charges Lithium-ion (LiFePO) batteries

• With up to 94% efficiency, the charger generates up to 4x less heat when compared to the industry standard

• Sustainable, safe and silent: Low thermal load, overheating protection, natural convection cooled

• Bluetooth functionality to set-up, monitor and update the charger

• Automatic voltage compensation

• Temperature compensated charging

• Storage Mode to extend battery life

• Reconditioning

• Alarm LED and remote on/off

• VE.Direct port

• Programmable relay

• Dimensions: 180mm(h) x 249mm(w) x 100mm(d)

• Weight: 3.5kg

• Phoenix Smart Charger: Choose from the dropdown menu

Click here for the Manual

Click here for the Phoenix Smart Charger (1+1) Diagram

Click here for the Phoenix Smart Charger (3) Diagram
