Epever Tracer-AN Series 5420 MPPT Solar Controller 12/24V 50A

Benefits & Features

• Advanced MPPT technology with efficiency 99.5%

• Ultra-fast tracking speed and guaranteed tracking efficiency

• Conversion efficiency up to 98.3%

• Multiphase synchronous rectification technology (MSRT)

• LCD display

• 3-stage charging

• Recognition and tracking of multiple-peaks maximum power point

• Auto control system to limit charging power and overcharging

• Compatible with lead-acid and lithium-ion batteries

• Functions: Battery temperature compensation, real-time data, overheating power reduction

• Caters up to 6 units in parallel

• Multiple load work modes

• Electronic protection

• Monitoring and setting with app or PV software

• Full-load operation in working environment temperature range within charging and discharging

• Voltage: 12/24/36/48V DC or Auto

• Rated Charge Current: 50A

• Weight: 3.5kg

• Dimensions: 261mm(l) x 216mm(w) x 119mm(h)

Click here for the Manual

Specifications

• Rated Charge Power: 625W/12V   1250W/24V  1875W/36V 2500/48V

• Max. PV Open Power Circuit Voltage: 180V (at 25°C environment temp), 200V (at minimum operating temp)

• Battery Voltage Range: 8 - 68V

• Common negative grounding

• RS485 Interface: RS485 (RJ45)

• Enclosure:  IP20

• Working Environment Temperature: -25°C - +60°C

• Relative Humidity: 5% - 95% (N.C.)
